Detailed Description
JOHN DEERE 1025R
200 HOURS
2021 YEAR
*****CALL STEPHEN 478*957*7009****
Engine power (gross) SAE J1995 rated power: 17.8 kW
23.9 hp
24.2 PS at 3200 rpm
Power take-off (PTO) power 12.8 kW
17.2 hp
Steering hydraulics 13.2 L/min
3.5 gpm
Implement hydraulics 13.2 L/min
3.5 gpm
Hitch type Limited Category 1
Lift capacity, 24-in. behind link arms 344 kg
758 lb
Standard transmission; forward/reverse Hydrostatic - two range
Cruise control Standard
Approximate shipping weight (open-station; cab) Open station: 706 kg
1556 lb
Cab: 906 kg
1996 lb
Wheelbase 1450 mm
57.1 in.
Key Specs
Manufacturer Yanmar®
Engine model 3TNV80F-NCJT
Engine power (gross) SAE J1995 rated power: 17.8 kW
23.9 hp
24.2 PS at 3200 seconds
Power take-off (PTO) power 12.8 kW
17.2 hp
Rated engine speed 3200 rpm
Type Diesel
Injection pump type Indirect injection
Aspiration Natural
Emissions compliance Final Tier 4
Cylinders/displacement Three cylinders: 1.267 L
77.3 cu in.
Number of cylinders Three
Cylinder liners Cast-in-block
Bore and stroke 80 x 84 mm
3.15 x 3.31 in.
Compression ratio 23.1:1
Lubrication Pressurized
Cooling system Water pump
Air cleaner Dual element with mechanical restriction indicator
Engine torque at rated speed 53.1 Nm
39.2 lb-ft
Fuel tank capacity 24 L
6.3 U.S. gal.
Engine
